How to: Create a Sleep Analytics App with Terra and ChatGPT


In this article, we are using Terra and the ChatGPT API to create a sleep analytics application.

We will be using Python and Flask to consume data from the Terra Webhook, and import sleep duration data from the Terra Graph API. We'll store respiration data with Flask-SQLAlchemy in an SQLite database, and display it using ChartJS. Additionally, we'll use the OpenAI API to display a short assessment of the breathing pattern.

Here is an image of the web application we are going to build:


Step 1 - Obtain Your Credentials from The Terra Dashboard

To communicate with a wearable through the Terra API, you need the following:

  • Your API Key
  • Your Dev ID

Go to your Terra Dashboard, under Connections, you will find your API Key and Dev ID in the bottom right corner in the API Credentials Popup. They are used in virtually every interaction with the API - keep them safe!

Step 2 - Create a Flask Webhook Consumer and Serve it with Ngrok

Create a virtual environment and activate it:

python -m venv env

source env/bin/activate

Install the necessary packages:

pip install Flask Flask-SQLAlchemy terra-python openai

The terra-python package is a wrapper for the Terra endpoints and models. We'll use it to verify and authenticate incoming webhook data.

Next, create a small Flask app file called app.py:

import logging
from flask import Flask, Response, request, render_template
from terra.base_client import Terra

logging.basicConfig(level=logging.INFO)
_LOGGER = logging.getLogger("app")

terra = Terra(api_key='<API-KEY>',
              dev_id='<DEV-ID>',
              secret='<SIGNING-SECRET>')

app = Flask(__name__)

@app.route("/", methods=["GET", "POST"])
def consume_terra_webhook() -> Response:
    if request.method == 'POST':
        # Get data from the Terra Webhook
        body = request.get_json()

        # Log that the Webhook was recieved
        _LOGGER.info(
            "Received webhook for user %s of type %s",
            body.get("user", {}).get("user_id"),
            body["type"])

        # Just a health check, return 200
        if body["type"] == 'healthcheck':
            return Response(status=200)

        # Verify Terra Signature
        verified = terra.check_terra_signature(request.get_data().decode("utf-8"),
                                            request.headers['terra-signature'])

        # The data is verified
        if verified:
            return Response(status=200)

        else:
            return Response(status=403)

    # Handle GET requests
    if request.method == 'GET':
        return render_template('index.html')

if __name__ == "__main__":
    app.run(host="localhost", port=8080)

Make sure to fill in <API-KEY> and <DEV-ID> with your API key and developer ID. The signing secret will be added later in this article.

This simple Flask web application serves as a webhook endpoint for Terra.

The code performs the following:

  1. Initializes logging with INFO level.
  2. Initializes a Terra client with the provided API key, and developer ID.
  3. Creates a Flask web application instance app.
  4. Defines a route ("/") that handles both GET and POST requests.

In the consume_terra_webhook() function, you have two conditions, one for handling POST requests and one for GET requests.

If the request is a POST request, this means that the Terra API has sent some data through a Webhook. So, the code does the following:

  1. Retrieves JSON data from the request body.
  2. Logs information about the received webhook, including user ID and data type.
  3. If the webhook type is a "healthcheck" respond with a 200 status.
  4. Verifies the Terra signature by comparing it with the calculated signature using the check_terra_signature() method. This will not work for now, as we haven't yet added a signing secret.
  5. In the if verified: condition, the signature is verified, so we respond with a 200 status for now; you will later modify this part of the code, so that it inserts data into a database. We will also respond with an HTTP 201 status code instead of 200 to signify that a resource was added to the server.
  6. If the signature is not verified, respond with a HTTP 403 FORBIDDEN status.

On the other hand, if the request is a GET request, the code renders an index.html template.

Now, create a templates folder inside your Flask app's directory and create a new index.html file inside it:

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>Terra Sleep Analytics</title>
    <!-- Add Chart.js CDN -->
    <script src="<https://cdn.jsdelivr.net/npm/chart.js>"></script>
</head>
<body>
    <div style="width:50%; margin:auto;">
        <h1>TERRA SLEEP ANALYTICS</h1>
        <h2 style='color: #de21ca'>Sleep Duration</h2>
        <iframe src="<https://api.tryterra.co/v2/graphs/11b605f5-328b-4b85-ac58-08fb2ed4264b/dummy_data?timeframe=7>"
                style="border:none;"
                height="300"
                width="500"
                title="sleep duration"></iframe>
    </div>
</body>
</html>

Save and close the file.

Here, you display an <iframe> of a Graph API. To get your own URL and use it in the src attribute. Go to the Terra GraphAPI Dashboard, and click Create Graph. Then, click the Give me sleep data for the last 7 days with an orange background on the right corner, or just ask for it in the prompt box at the bottom.

You should see an orange Graph generated on the left, copy your graph's unique URL and paste it in the src attribute in your <iframe> inside your index.html template.

Notes: If you want to generate other graphs, you can just describe them and Terra's magic AI will create them for you :)

Next Run the application on port 8080:

flask --app app run -p 8080

As Terra cannot send Webhook data to your local development server, you have to expose your server to the Internet using Ngrok. To install it, check out this page.

Once you install Ngrok, create an account, then obtain your authentication token from the Ngrok dashboard. Once you get your authtoken, add it to your Ngrok agent using the following command:

ngrok config add-authtoken <TOKEN>

This will allow you to access some features such as rendering HTML files.

Once you set up Ngrok, use it to expose your Flask application that is currently running on port 8080:

ngrok http 8080

This command will give you a URL under Forwarding. Use your browser to access this URL, you should see your index page with the sleep duration graph you generated earlier:


Copy your Ngrok URL. This is your Server URL, and you will use it to connect to a Terra Webhook in the next step.

Step 3 - Connect a Terra Webhook with Your Server

You will now connect a test wearable with your Flask app.

Note: We will use FitBit in this demo.

Go to your Terra Dashboard, then in Connections. Under Sources, click Add Sources, and select Fitbit, then Save.

Next, under Destinations click Add Destination, then select Webhook, then Next.

Put your Ngrok Server URL under host.

The Connections dashboard should now look like so:


Now, you need to obtain your Signing secret. Click the three dots to the right of Webhook then Edit.

Copy the Signing secret. This is needed to authenticate and verify Webhook requests.

To use your Webhook's signing secret, modify the secret parameter in your Terra initiation inside your app.py Flask application:

terra = Terra(api_key='<API-KEY>',
              dev_id='<DEV-ID>',
              secret='<PASTE-SIGNING-SECRET-HERE>')

Once modified, remember to rerun your Flask app:

flask --app app run -p 8080

Note: Make sure Ngrok is still running. If you've stopped it and restarted it, your Server URL will change, so make sure to edit the Webhook host in your Terra Dashboard and replace the old Ngrok URL with the new one.

We will now test the Webhook connection. In the Terra Dashboard, go to Tools > Generate > Select Data Source > Fitbit.

Then click on Sleep, then click Generate test data.

Once data is generated. Click Send to Webhook.

Go back to your Flask server and wait for a few seconds. You should see the following message in the logs:

INFO:app:Received webhook for user <Your User ID> of type sleep
INFO:werkzeug:127.0.0.1 - - [06/Dec/2023 21:08:07] "POST / HTTP/1.1" 200 -

This means you have successfully connected a Terra Webhook with your Flask application and you are receiving data! Next, you'll modify app.py to store the data inside an SQLite database.

Step 4 - Storing Sleep Respiration Data in an SQLite Database

Now that you are receiving wearable data from the Terra Webhook, you can use Flask-SQLAlchemy to store this data in an SQL database. We will use an SQLite database in this demonstration.

Open your app.py file and modify it by importing and setting up Flask-SQLAlchemy, then adding a new Breath database model, so that everything above the @app.route("/", methods=["GET", "POST"]) line looks as follows:

# app.py
import logging

from flask import Flask, Response, request, render_template
from flask_sqlalchemy import SQLAlchemy

from terra.base_client import Terra

logging.basicConfig(level=logging.INFO)
_LOGGER = logging.getLogger("app")

terra = Terra(api_key='<API-KEY>',
              dev_id='<DEV-ID>',
              secret='<SIGNING-SECRET>')

app = Flask(__name__)

app.config['SQLALCHEMY_DATABASE_URI'] = 'sqlite:///app.db'

db = SQLAlchemy(app)

# Datatbase Table for Sleep Respiration Data
class Breath(db.Model):
    __tablename__ = 'breaths_data'
    id = db.Column(db.Integer, primary_key=True)
    timestamp = db.Column(db.String)
    breaths_per_min = db.Column(db.Integer)

Save and close the file.

Here, you set up a database URI that will point to an SQLite database called app.db. This database file will be created inside a new instance folder that will be automatically added to your Flask project folder.

You also add a Flask-SQLAlchemy database model that represents a table called Breath with a column for an ID, a timestamp, and a breaths per minute value, these last two items are provided to us by the Terra Sleep API.

Next, inside your Flask application folder, with your environment activated, open the Flask Shell to create the database file and Breath respiration data table:

flask shell
>>> from app import db, Breath
>>> db.create_all()
>>> exit()

You should see a new app.db file inside an instance folder in your Flask project folder.

Next, modify the if verified condition code in your app.py, where you handle POST requests, from this:

# ...
        # The data is verified
        if verified:
            return Response(status=200)

To this:

# ....
        # The data is verified
        if verified:
            breaths_samples = body['data'][0]['respiration_data']\\
                                  ['breaths_data']['samples']

            # Add timestamps & respiration data to a DB
            _LOGGER.info("Adding timestamps and breaths_per_min to the DB")
            for sample in breaths_samples:
                db_breath_sample = Breath(timestamp=sample['timestamp'],
                                           breaths_per_min=sample['breaths_per_min'])
                db.session.add(db_breath_sample)

            # Apply changes to the database
            db.session.commit()

            return Response(status=201)
# ....

Save and close the file.

Here, you extract the respiration data from the body variable, which holds the Sleep data sent by the Terra API. You Log the database insertion, then loop through the provided samples and insert each timestamp and its corresponding breaths per minute value into the database session.

Finally, you call db.session.commit() to apply changes to the database, then respond with an HTTP 201 status code.

The full file should now be like this:

# app.py
import logging

from flask import Flask, Response, request, render_template
from flask_sqlalchemy import SQLAlchemy

from terra.base_client import Terra

logging.basicConfig(level=logging.INFO)
_LOGGER = logging.getLogger("app")

terra = Terra(api_key='<API-KEY>',
              dev_id='<DEV-ID>',
              secret='<SIGNING-SECRET>')

app = Flask(__name__)

app.config['SQLALCHEMY_DATABASE_URI'] = 'sqlite:///app.db'

db = SQLAlchemy(app)

# Datatbase Table for Sleep Respiration Data
class Breath(db.Model):
    __tablename__ = 'breaths_data'
    id = db.Column(db.Integer, primary_key=True)
    timestamp = db.Column(db.String)
    breaths_per_min = db.Column(db.Integer)

@app.route("/", methods=["GET", "POST"])
def consume_terra_webhook() -> Response:
    if request.method == 'POST':
        # Get data from the Terra Webhook
        body = request.get_json()

        # Log that the Webhook was recieved
        _LOGGER.info(
            "Received webhook for user %s of type %s",
            body.get("user", {}).get("user_id"),
            body["type"])

        # Just a health check, return 200
        if body["type"] == 'healthcheck':
            return Response(status=200)

        # Verify Terra Signature
        verified = terra.check_terra_signature(request.get_data().decode("utf-8"),
                                            request.headers['terra-signature'])

       # The data is verified
        if verified:
            breaths_samples = body['data'][0]['respiration_data']\\
                                  ['breaths_data']['samples']

            # Add timestamps & respiration data to a DB
            _LOGGER.info("Adding timestamps and breaths_per_min to the DB")
            for sample in breaths_samples:
                db_breath_sample = Breath(timestamp=sample['timestamp'],
                                           breaths_per_min=sample['breaths_per_min'])
                db.session.add(db_breath_sample)

            # Apply changes to the database
            db.session.commit()

            return Response(status=201)

        else:
            return Response(status=403)

    # Handle GET requests
    if request.method == 'GET':
        return render_template('index.html')

if __name__ == "__main__":
    app.run(host="localhost", port=8080)

To test that this new added code works, go back to the Terra Dashboard, generate new data, then click Send to Webhook.

Note: You may need to restart your Flask server.

You should see the following two lines in your Flask server logs:

INFO:app:Adding timestamps and breaths_per_min to the DB
INFO:werkzeug:127.0.0.1 - - [16/Dec/2023 13:55:23] "POST / HTTP/1.1" 201 -

With the wearable data now stored inside our database, we can modify our Flask application and use ChartJS to add a graph that showcases the number of breaths per minute during sleep.

Step 5 - Adding a Sleep Respiration Tracker with ChartJS

To create the sleep respiration tracker, we will modify the part of code that handles GET requests.

Open app.py, then add a datetime import and a new date_time_format() function above the @app.route("/", methods=["GET", "POST"]) line.

import logging
from datetime import datetime

from flask import Flask, Response, request, render_template
from flask_sqlalchemy import SQLAlchemy

from terra.base_client import Terra

# ...
# ...
# ...

# Function to format timestamps to '%Y-%m-%d %H:%M:%S'
# (Makes the ChartJS graph easier to read)
def date_time_format(timestamp):
    return datetime.fromisoformat(timestamp[:-6]).strftime('%Y-%m-%d %H:%M:%S')

@app.route("/", methods=["GET", "POST"])
# ...

Note: The rest of the code is omitted and referenced as # .... The date_time_format() function will be used to make timestamps easier to read.

Next, modify the GET request handler from this:

    # Handle GET requests
    if request.method == 'GET':
        return render_template('index.html')

To this:

    # Handle GET requests
    if request.method == 'GET':
        # Get the latest 10 breath samples from the database
        latest_breath_samples = Breath.query.order_by(
                                Breath.timestamp.desc()) \\
                                .limit(10).all()[::-1]

        # Extract timestamps & make them readable
        timestamps = [date_time_format(s.timestamp) for s in latest_breath_samples]
        # Extract breaths_per_min values
        breaths_per_min  = [s.breaths_per_min for s in latest_breath_samples]

        return render_template('index.html',
                               timestamps=timestamps,
                               breaths_per_min=breaths_per_min)

Here, you get the latest 10 breath samples from the database, extract timestamps and make them readable, then extract breaths per minute. You then pass these two extracted values to the index.html template.

To display the respiration data you just passed, open the index.html template and add the following <h2>, <div>, and <script> below the previous <iframe> and just above the ending </div> tag. So that the <body> contents look as follows:

<body>
    <div style="width:50%; margin:auto;">
        <h1>TERRA SLEEP ANALYTICS</h1>
        <h2 style='color: #de21ca'>Sleep Duration</h2>
        <iframe src="<https://api.tryterra.co/v2/graphs/11b605f5-328b-4b85-ac58-08fb2ed4264b/dummy_data?timeframe=7>"
                style="border:none;"
                height="300"
                width="500"
                title="sleep duration"></iframe>

        <h2 style='color: #de21ca'>Breaths per Minute</h2>
        <div style="height: 250px">
            <canvas id="barChart"></canvas>
        </div>

        <script>
            document.addEventListener('DOMContentLoaded', function () {
                var ctx = document.getElementById('barChart').getContext('2d');
                var myChart = new Chart(ctx, {
                    type: 'line',
                    data: {
                        labels: {{ timestamps | tojson | safe }},
                        datasets: [{
                            label: 'Breaths per Minute',
                            data: {{ breaths_per_min | tojson | safe }},
                            backgroundColor: 'rgba(75, 192, 192, 0.2)',
                            borderColor: 'rgba(75, 192, 192, 1)',
                            borderWidth: 1
                        }]
                    },
                    options: {
                        scales: {
                            y: {
                                beginAtZero: true
                            }
                        }
                    }
                });
            });
        </script>
   </div>
</body>

The new ChartJS code generates a line chart with the provided timestamps and respiration values.

To test out the application, make sure your Flask server is running, and use your browser to access your Ngrok Server URL. You should see a new line chart showcasing the number breaths per minutes for each timestamp.

Next, you'll add a new feature using AI, and provide a breathing pattern assessment.

Step 6 - Adding a Breathing Pattern Assessment using the OpenAI API

We will now use the OpenAI API (also known as ChatGPT API) to provide a breathing pattern assessment feature in our application.

Inside your Flask project, open a new file called gpt.py then add the following code to it:

import os
from openai import OpenAI

client = OpenAI(
    api_key=os.environ.get("OPENAI_API_KEY"),
)

def ask(question):
    completion = client.chat.completions.create(
    model="gpt-3.5-turbo",
    messages=[
        {"role": "system", "content": """
        You analyse data from a sleep monitor for adults,
        and respond with either "Normal Breathing" or "Abnormal Breathing"
        Your response should have no explanations, no additional information,
        only the response,
        which should either be "Normal Breathing" or "Abnormal Breathing".
        """},
        {"role": "user", "content": question}
    ]
    )

    return completion.choices[0].message.content

Save and close the file.

Here, you set up an OpenAI client, passing your OpenAI API key as an environment variable.

In the ask() function, you set up a question that essientialy assesses the breathing pattern from the data it recieves. The response will either be "Normal Breathing" or "Abnormal Breathing".

Now, set your Open API key in an environment variable.

For Linux & MacOS:

export OPENAI_API_KEY='your Open API key'

For Windows:

set OPENAI_API_KEY='your Open API key'

Next, inside your app.py file, add a gpt import at the top:

import logging
from datetime import datetime

from flask import Flask, Response, request, render_template
from flask_sqlalchemy import SQLAlchemy

from terra.base_client import Terra

import gpt

Then use the gpt.ask() function in the part of code where you handle GET requests, just before you render the index.html template, and pass the answer to this same template:

        # Ask ChatGPT to assess the breathing pattern
        breath_analysis = gpt.ask(f"""Analyse the following data:
                            Timestamps: {timestamps},
                            Breaths per minute:{breaths_per_min},
                            """)

        return render_template('index.html',
                               timestamps=timestamps,
                               breaths_per_min=breaths_per_min,
                               breath_analysis=breath_analysis)

Here you ask ChatGPT using the ask() function to provide a breathing pattern assessment based on the timestamps and number of breaths per minute.

Next, modify your index.html template to display the breathing pattern assessment. To do so, add the following <h1> below the ChartJS canvas and above the <script> tag:

        <div style="height: 250px">
            <canvas id="barChart"></canvas>
        </div>

        <h1 style="color: #437019">Respiration conclusion: {{ breath_analysis }}</h1>

    <script>

With this, you should see the assessment in your application under Respiration conclusion:


Conclusion

Congrats! You've learned how to use the Terra API to make a Sleep Analytics App.

To learn more about the awesome things you can build with Terra, check out the following pages:

More Topics

All Blogs
Team Spotlight
Startup Spotlight
How To
Blog
Podcast
Product Updates
Wearables
See All >
Founder of Don’t Die - Bryan Johnson

Founder of Don’t Die - Bryan Johnson

In this podcast, Bryan Johnson shares his personal story of how he began his journey to becoming the the world's most measured human.

Terra APITerra API
October 25, 2024
CEO and Co-Founder of Veri - Anttoni Aniebonam

CEO and Co-Founder of Veri - Anttoni Aniebonam

In this podcast with Kyriakos the CEO of Terra, Anttoni Aniebonam shares his journey founding Veri, and his decision in the acquisition by Oura to further his vision.

Terra APITerra API
September 27, 2024
CEO and Founder of Prenuvo - Andrew Lacy

CEO and Founder of Prenuvo - Andrew Lacy

In this podcast with Kyriakos the CEO of Terra, Andrew Lacy shares his journey with Prenuvo which began from a personal health crisis.

Terra APITerra API
August 28, 2024
MedHacks: Using Wearables To Predict Heart Attacks

MedHacks: Using Wearables To Predict Heart Attacks

A few weeks ago we met Vishal, a recent engineering graduate who wanted to use Terra API as part of his MedHacks hackathon project, Cardio Clarity.

Gursukh SembiGursukh Sembi
August 19, 2024
Chief Digital Product Officer of Les Mills - Amber Taylor

Chief Digital Product Officer of Les Mills - Amber Taylor

In this podcast with Kyriakos the CEO of Terra, Amber Taylor shares her journey from childhood running to her leadership role at Nike and navigating cultural differences.

Terra APITerra API
August 2, 2024
next ventures
pioneer fund
samsung next
y combinator
general catalyst

Cookie Preferences

Essential CookiesAlways On
Advertisement Cookies
Analytics Cookies

Crunch Time: Embrace the Cookie Monster Within!

We use cookies to enhance your browsing experience and analyse our traffic. By clicking “Accept All”, you consent to our use of cookies according to our Cookie Policy. You can change your mind any time by visiting out cookie policy.
