WHOOP Integration series Part 2: Data available from the API

With WHOOP's recent announcement of their open API, we at Terra were very excited to see what we can get from their API.

API vs Device Data

WHOOP's API currently can only provide a top-level summary of the user's health data: how well they slept, how much strain they put their body through, and how well did they recover.

Sleep and Recovery: The device provides you with a detailed analysis of how you've slept for a night, providing resting heart rates, heart rate variability, respiratory rates, amount of time spent in each sleep stage, amount of wake up events, and your heart rates over the night. If we take an example here, we can see WHOOP displays the following for a night of sleep and recovery over the week.

Most of the data points above can be retrieved from the API. This would populate respective fields in Terra's sleep data payload. For example, for the night of sleep above, the payload below is returned.

  {
      "readiness_data": {
          "readiness": 76.0,
          "recovery_level": 0
      },
      "device_data": {
          "other_devices": [],
          "activation_timestamp": null,
          "manufacturer": null,
          "software_version": null,
          "serial_number": null,
          "name": null,
          "hardware_version": null
      },
      "metadata": {
          "start_time": "2022-09-11T01:08:42.703000+07:00",
          "is_nap": false,
          "end_time": "2022-09-11T10:02:11.493000+07:00",
          "upload_type": 1
      },
      "temperature_data": {
          "delta": null
      },
      "sleep_durations_data": {
          "other": {
              "duration_in_bed_seconds": null,
              "duration_unmeasurable_sleep_seconds": 0.0
          },
          "asleep": {
              "duration_asleep_state_seconds": 30086.76,
              "num_REM_events": 4,
              "duration_REM_sleep_state_seconds": 8201.357,
              "duration_deep_sleep_state_seconds": 5342.427,
              "duration_light_sleep_state_seconds": 16542.976
          },
          "sleep_efficiency": 0.9442353,
          "hypnogram_samples": [],
          "awake": {
              "num_wakeup_events": 12,
              "wake_up_latency_seconds": null,
              "num_out_of_bed_events": null,
              "duration_long_interruption_seconds": null,
              "duration_awake_state_seconds": 1776.865,
              "duration_short_interruption_seconds": null,
              "sleep_latency_seconds": null
          }
      },
      "respiration_data": {
          "breaths_data": {
              "start_time": null,
              "max_breaths_per_min": null,
              "avg_breaths_per_min": 15.058594,
              "end_time": null,
              "on_demand_reading": null,
              "samples": [],
              "min_breaths_per_min": null
          },
          "oxygen_saturation_data": {
              "start_time": null,
              "end_time": null,
              "samples": [],
              "avg_saturation_percentage": 97.63333
          },
          "snoring_data": {
              "start_time": null,
              "end_time": null,
              "total_snoring_duration_seconds": null,
              "samples": [],
              "num_snoring_events": null
          }
      },
      "heart_rate_data": {
          "summary": {
              "avg_hrv_sdnn": null,
              "user_max_hr_bpm": null,
              "resting_hr_bpm": 59.0,
              "avg_hrv_rmssd": 60.33115,
              "min_hr_bpm": null,
              "avg_hr_bpm": null,
              "max_hr_bpm": null
          },
          "detailed": {
              "hrv_samples_rmssd": [],
              "hr_samples": [],
              "hrv_samples_sdnn": []
          }
      }
  }

Strain: WHOOP also provides a detailed breakdown of how much strain the user has put on their body. This comes in a strain score going between 0 and 21. This score accumulates over the day as the user completes workouts, or simply by performing everyday tasks.

If we take a look at the device, the workout performed on the left produced a strain of 14.6 which on a corresponding day, produced a total strain of 18.1. The workout has details on how much time was spent on each HR zone along with heart rate statistics, calories and duration data.

The workout details above can be retrieved by Terra's API as shown below:

{
    "oxygen_data": {
        "avg_saturation_percentage": null,
        "vo2max_ml_per_min_per_kg": null,
        "vo2_samples": [],
        "saturation_samples": []
    },
    "polyline_map_data": {
        "summary_polyline": null
    },
    "metadata": {
        "type": 108,
        "country": null,
        "summary_id": 510541643,
        "state": null,
        "start_time": "2022-09-15T12:59:50.889000+08:00",
        "name": "Activity",
        "end_time": "2022-09-15T14:45:33.507000+08:00",
        "city": null,
        "upload_type": 1
    },
    "strain_data": {
        "strain_level": 14.604
    },
    "distance_data": {
        "summary": {
            "swimming": {
                "num_laps": null,
                "pool_length_meters": null,
                "num_strokes": null
            },
            "steps": null,
            "floors_climbed": null,
            "elevation": {
                "avg_meters": null,
                "gain_planned_meters": null,
                "loss_actual_meters": null,
                "gain_actual_meters": 0.0,
                "min_meters": null,
                "max_meters": null
            },
            "distance_meters": 0.0
        },
        "detailed": {
            "distance_samples": [],
            "floors_climbed_samples": [],
            "elevation_samples": [],
            "step_samples": []
        }
    },
    "heart_rate_data": {
        "summary": {
            "user_max_hr_bpm": null,
            "min_hr_bpm": null,
            "max_hr_bpm": 167,
            "hr_zone_data": [
                {
                    "end_percentage": 50,
                    "duration_seconds": 0.0,
                    "name": "Resting",
                    "start_percentage": 0,
                    "zone": 0
                },
                {
                    "end_percentage": 60,
                    "duration_seconds": 339.38,
                    "name": "Very light",
                    "start_percentage": 50,
                    "zone": 1
                },
                {
                    "end_percentage": 70,
                    "duration_seconds": 2058.107,
                    "name": "Light",
                    "start_percentage": 60,
                    "zone": 2
                },
                {
                    "end_percentage": 80,
                    "duration_seconds": 2552.245,
                    "name": "Moderate",
                    "start_percentage": 70,
                    "zone": 3
                },
                {
                    "end_percentage": 90,
                    "duration_seconds": 1392.925,
                    "name": "Hard",
                    "start_percentage": 80,
                    "zone": 4
                },
                {
                    "end_percentage": 100,
                    "duration_seconds": 0.0,
                    "name": "Maximum",
                    "start_percentage": 90,
                    "zone": 5
                }
            ],
            "avg_hr_bpm": 134,
            "avg_hrv_sdnn": null,
            "avg_hrv_rmssd": null,
            "resting_hr_bpm": null
        },
        "detailed": {
            "hrv_samples_rmssd": [],
            "hrv_samples_sdnn": [],
            "hr_samples": []
        }
    },
    "power_data": {
        "avg_watts": null,
        "power_samples": [],
        "max_watts": null
    },
    "active_durations_data": {
        "low_intensity_seconds": 2058.107,
        "activity_levels_samples": [],
        "activity_seconds": null,
        "rest_seconds": null,
        "moderate_intensity_seconds": 2552.245,
        "inactivity_seconds": 339.38,
        "num_continuous_inactive_periods": null,
        "vigorous_intensity_seconds": 1392.925
    },
    "energy_data": {
        "energy_kilojoules": 4064.4888,
        "energy_planned_kilojoules": null
    }
    ...
}

Left Out

From the data points analyzed above, you may have noticed two very important fields missing that are shown on the device but not retrieved by the API:

Heart Rates

WHOOP provides a dashboard with all the user's heart rates measured by the device (at 1 minute intervals). This information are used by many developers to make in-depth analytics on their users' health profile.

Sleep Samples

WHOOP provides in detail the times the user goes from awake to light sleep, light sleep to deep sleep, deep sleep to rem sleep and etc. This information is essential for apps that wish to track sleep closely for their users. Knowing when they go from light sleep to deep sleep allows the developer to further suggest how to maximize the time spent in deep sleep (for better recovery).

API Potentials

The device data left out of the API are common data fields provided by fitness wearable companies such as GARMIN, FITBIT, and OURA in their APIs. They are what enable developers to make truly personalized apps that can change the health and fitness market.

We at Terra enable our developers to do so already by providing as much data as possible from every integration we do, from our fitness API.


In our Integration series on WHOOP, we are discussing the data available from our API when fetching data from WHOOP.

As a reminder, the WHOOP series contains:

  • Part 1: Getting started with Rest APIs
  • Part 2: Data available from the API
  • Part 3: Integrating with Terra API
  • Part 4: Data from TERRA API
